A24 Retrofit Stack Parker
The independent stack parking system
Retrofit, budgetary solution. This mechanical parking system allows two cars to be parked in the footprint of one car. Both platforms move vertically up and down together enabling any car to be retrieved independently at a ground level. A pit is required one level below the ground level. This system also comes with the option of double platform.
SPECIFICATION
- For independent parking
- Single platform (SP) for 2 cars or double platform (DP) for 4 cars, retrofit model
- Pit depth: 175 to 225 cm
- Horizontal access to the parking levels
- Sequential vertical movement of a platform
- Vehicle dimensions: height 150 to 210 cm, length 500 – 520 cm
- Standard design: 2,000 kg, optional max. 2,500 kg SP/DP
- Suitable for: residential and commercial buildings, hotels as well as family homes and apartment building
For more specific information, please download a complete datasheet of the product.
